Ariston Diverter Valve 3 Way Spring Kit (60001583 | 60001583-01 | 65104314)
The Ariston Diverter Valve 3 Way Spring Kit (Part Nos: 60001583, 60001583-01, or 65104314) is a specialized internal component service kit engineered for the motorized 3-way diverter valves used across Ariston's modern condensing combination and system boiler ranges. This kit replaces the high-tension mechanical return spring, central sealing cartridge stem, internal bypass shuttles, and critical O-ring seals within the hydro-block structure. By renewing these core components, it ensures the actuator motor can successfully compress and release the valve mechanism to switch primary heated water cleanly between the central heating circuit and the domestic plate heat exchanger.
Spring Tension Restoration: Replaces weak, fatigued, or corroded internal return springs that cause the mechanical cartridge to bind or fail to return to its default heating position.
Positive Flow Isolation: Restores precise internal gate sealing to completely eradicate central heating "cross-bleed," preventing radiators from warming up when only domestic hot water is demanded.
Low-Friction Operation: Features high-tolerance internal components designed to glide smoothly within composite polymer hydraulic blocks, minimizing mechanical strain on the electronic actuator motor.
Targeted Internal Fix: Allows for a precise mechanical rebuild of the valve's dynamic internals, eliminating the need to source and install a complete, expensive hydraulic manifold block. Compatible Models:
Ariston Clas HE Series
Clas HE 24 (Edition 5) — 47-116-51
Clas HE 24 (Edition 7) — 47-116-51 EDITION 7
Clas HE 30 (Edition 5) — 47-116-52
Clas HE 30 (Edition 7) — 47-116-52 EDITION 7
Clas HE 38 (Edition 5) — 47-116-53
Clas HE 38 (Edition 7) — 47-116-53 EDITION 7
Clas HE Evo 24 — 47-116-65
Clas HE Evo 30 — 47-116-66
Clas HE Evo 38 — 47-116-67
Clas HE Evo System 18 — 41-116-36
Clas HE Evo System 24 — 41-116-37
Clas HE Evo System 30 — 41-116-38
E Combi 24 FF (Edition 4) — 47-116-62 EDITION 4
E Combi 30 FF (Edition 4) — 47-116-63 EDITION 4
E Combi 38 FF (Edition 4) — 47-116-64 EDITION 4
Genus HE 24 (Edition 5) — 47-116-54
Genus HE 24 (Edition 7) — 47-116-54 EDITION 7
Genus HE 30 (Edition 5) — 47-116-55
Genus HE 30 (Edition 7) — 47-116-55 EDITION 7
Genus HE 38 (Edition 5) — 47-116-56
Genus HE 38 (Edition 7) — 47-116-56 EDITION 7
